This type of pump is used for irrigating small gardens, supplying clean water in temporary installations, handling non-corrosive liquids, and filling/emptying tanks and small pools. Easy to carry thanks to its handle and low weight.
It is equipped with an electric float switch for automatic start and stop of the pump when the water level drops below the minimum level.
Thanks to the materials used to manufacture the pump, ABS and stainless steel, the risk of rust is greatly reduced.
On the lower part of the pump body there is a ring that lets you set the pump for clean or dirty water.
By rotating the ring to 23 mm, the inlet slots are fully open. This setting is used for dirty water with impurities up to 5 mm. In this case the pump delivers the highest (maximum) flow.
By rotating the ring to 1 mm, the inlet slots are almost closed. In this case, water can be pumped from the lowest level mentioned in the technical documentation.
Technical data:
material: ABS and stainless steel;
winding: aluminum;
pressure: 0.85 / 1.05 bar;
water temperature: max. 35 ºC;
flow rate: 266.66 / 308.33 l/min;
maximum immersion depth: 7 m;
maximum head: 8.5 / 10.5 m;
voltage: 230 V, 50 Hz;
cable length: 10 m;
connection: 1", 1 1/2", 25 mm, 32 mm;
maximum particle diameter: 5 mm;
protection rating: IPX8;
